Strainer DN100(4") 56mesh
The product shown in the picture may differ from the product sold.
Strainer DN100(4") 56mesh
Article-No.: 08414.0114.0007
Price
POR
Description
cryogenic strainer DN100 PN50
cleaned and degreased for oxygen service
working temperature -196°C up to +120°C
body 1.4308 st.st.
screen 1.4301 st.st. mesh size 0.25mm ( 55 mesh)
cap CC493K bronze
connection butt weld OD114.3mm x 6.02mm
face to face 280mm
height 166mm
cleaned and degreased for oxygen service
working temperature -196°C up to +120°C
body 1.4308 st.st.
screen 1.4301 st.st. mesh size 0.25mm ( 55 mesh)
cap CC493K bronze
connection butt weld OD114.3mm x 6.02mm
face to face 280mm
height 166mm
Currently out of stock
Delivery Times
On Stock:
Out-Of Stock:
The actual delivery time will be determined individually and is part of the order confirmation.
Live Stock: Out-Of Stock pcs (ON STOCK)
More Information
| SKU | 08414.0114.0007 |
|---|---|
| Solution | LNG, Air Gases |
| Solution Area | Transport, Storage, Refueling, Processes |
| HEROSE Type Reference | CR_08414 |
| Type (Series) | 08414 |
| Maximum allowable temperature | -196.0 °C |
| Maximum allowable temperature | 120.0 °C |
| cleaned for oxygen service | ISO 23208 |
| nominal size | DN 100 |
| Nominal pressure | PN 50 |
| Kvs-value | 115.0 MQH |
| body material | 1.4308 |
| CV-Value | 133,1 gal/min |
| Connection dimension inlet | 114,3 x 6,3 / 4'' S40 |
| Connection dimension outlet | 114,3 X 6,3 / 4'' S40 |
| Connection inlet | welding end |
| Connection outlet | welding end |
| Canada approval | CRN 0E14408.5C |
Related Type
Datasheet ID: CR_08414
Type 08414 - Strainer
Datasheet ID: CR_08414
- Solution:
- LNG, Air Gases
- Solution Area:
- Transport, Storage, Refueling, Processes
