Gate Valve DN65(2 1/2") H440
Connection outlet:
female thread NPT
Connection inlet:
female thread NPT
Connection dimension outlet:
2.1/2''
Connection dimension inlet:
2.1/2''
CV-Value:
337,0 gal/min
Kvs-value:
283.0 MQH
Nominal pressure:
PN 50
nominal size:
DN 65
cleaned for oxygen service:
ISO 23208
Maximum allowable temperature:
120.0 °C
Maximum allowable temperature:
-196.0 °C
installation height:
440.0 MMT
Article-No.: 09345.2400.0026
Price
Open product details
main_de
Gate Valve DN40(1 1/2") H560
Connection outlet:
welding end
Connection inlet:
welding end
Connection dimension outlet:
48,3 X 2,6 / 1.1/2'' S10
Connection dimension inlet:
48,3 X 2,6 / 1.1/2'' S10
CV-Value:
111.0 gal/min
Kvs-value:
93.0 MQH
Nominal pressure:
PN 50
nominal size:
DN 40
cleaned for oxygen service:
ISO 23208
Maximum allowable temperature:
120.0 °C
Maximum allowable temperature:
-196.0 °C
installation height:
560.0 MMT
Article-No.: 09343.4048.W022
Price
Open product details
main_de
Gate Valve DN50(2") H590
Connection outlet:
welding end
Connection inlet:
welding end
Connection dimension outlet:
60,3 X 2,6 / 2'' S10
Connection dimension inlet:
60,3 X 2,6 / 2'' S10
CV-Value:
149,0 gal/min
Kvs-value:
125.0 MQH
Nominal pressure:
PN 50
nominal size:
DN 50
cleaned for oxygen service:
ISO 23208
Maximum allowable temperature:
120.0 °C
Maximum allowable temperature:
-196.0 °C
installation height:
590.0 MMT
Article-No.: 09343.5060.H022
Price
Open product details
main_de
Gate Valve DN65(2 1/2") H530
Connection outlet:
SCHWEIßKUGELBUCHSE
Connection inlet:
SCHWEIßKUGELBUCHSE
Connection dimension outlet:
70
Connection dimension inlet:
70
CV-Value:
337,0 gal/min
Kvs-value:
283.0 MQH
Nominal pressure:
PN 50
nominal size:
DN 65
cleaned for oxygen service:
ISO 23208
Maximum allowable temperature:
120.0 °C
Maximum allowable temperature:
-196.0 °C
installation height:
530.0 MMT
Article-No.: 09443.6570.T014
Price
Open product details
main_de
Gate Valve DN40(1 1/2") H560
Connection outlet:
SCHWEIßKUGELBUCHSE
Connection inlet:
SCHWEIßKUGELBUCHSE
Connection dimension outlet:
42
Connection dimension inlet:
42
CV-Value:
111.0 gal/min
Kvs-value:
93.0 MQH
Nominal pressure:
PN 50
nominal size:
DN 40
cleaned for oxygen service:
ISO 23208
Maximum allowable temperature:
120.0 °C
Maximum allowable temperature:
-196.0 °C
installation height:
560.0 MMT
Article-No.: 09443.4042.T024
Price
Open product details
main_de
Gate Valve DN50(2") H590
Connection outlet:
socket weld
Connection inlet:
socket weld connection
Connection dimension outlet:
57
Connection dimension inlet:
57
CV-Value:
149,0 gal/min
Kvs-value:
125.0 MQH
Nominal pressure:
PN 50
nominal size:
DN 50
cleaned for oxygen service:
ISO 23208
Maximum allowable temperature:
120.0 °C
Maximum allowable temperature:
-196.0 °C
installation height:
590.0 MMT
Article-No.: 09343.5057.T024
Price
Open product details
main_de
Gate Valve DN100(4") H670
Connection outlet:
socket weld
Connection inlet:
socket weld connection
Connection dimension outlet:
114,3 / 4''
Connection dimension inlet:
114,3 / 4''
CV-Value:
943,0 gal/min
Kvs-value:
792.0 MQH
Nominal pressure:
PN 50
nominal size:
DN 100
cleaned for oxygen service:
ISO 23208
Maximum allowable temperature:
120.0 °C
Maximum allowable temperature:
-196.0 °C
installation height:
670.0 MMT
Article-No.: 09340.0114.0024
Price
Open product details
main_de
Gate Valve DN65(2 1/2") H530
Connection outlet:
welding end
Connection inlet:
welding end
Connection dimension outlet:
2.1/2'' S10
Connection dimension inlet:
2.1/2'' S10
CV-Value:
337,0 gal/min
Kvs-value:
283.0 MQH
Nominal pressure:
PN 50
nominal size:
DN 65
cleaned for oxygen service:
ISO 23208
Maximum allowable temperature:
120.0 °C
Maximum allowable temperature:
-196.0 °C
installation height:
530.0 MMT
Article-No.: 09343.6573.T011
Price
Open product details
main_de
Gate Valve DN25(1") H430
Connection outlet:
socket weld
Connection inlet:
socket weld connection
Connection dimension outlet:
33,7 / 1''
Connection dimension inlet:
33,7 / 1''
CV-Value:
51,0 gal/min
Kvs-value:
43.0 MQH
Nominal pressure:
PN 50
nominal size:
DN 25
cleaned for oxygen service:
ISO 23208
Maximum allowable temperature:
120.0 °C
Maximum allowable temperature:
-196.0 °C
installation height:
430.0 MMT
Article-No.: 09340.2533.0024
Price
Open product details
main_de
Gate Valve DN65(2 1/2") H630
Connection outlet:
welding end
Connection inlet:
welding end
Connection dimension outlet:
76,1 X 2,3
Connection dimension inlet:
76,1 X 2,3
CV-Value:
337,0 gal/min
Kvs-value:
283.0 MQH
Nominal pressure:
PN 50
nominal size:
DN 65
cleaned for oxygen service:
ISO 23208
Maximum allowable temperature:
120.0 °C
Maximum allowable temperature:
-196.0 °C
installation height:
630.0 MMT
Article-No.: 09343P6576.T021
Price
Open product details
main_de
Gate Valve DN100(4") H880
Connection outlet:
socket weld
Connection inlet:
socket weld connection
Connection dimension outlet:
114,3 / 4''
Connection dimension inlet:
114,3 / 4''
CV-Value:
943,0 gal/min
Kvs-value:
792.0 MQH
Nominal pressure:
PN 50
nominal size:
DN 100
cleaned for oxygen service:
ISO 23208
Maximum allowable temperature:
120.0 °C
Maximum allowable temperature:
-196.0 °C
installation height:
880.0 MMT
Article-No.: 09343.0114.T024
Price
Open product details
main_de
Gate Valve DN65(2 1/2") H440
Connection outlet:
welding end
Connection inlet:
welding end
Connection dimension outlet:
76,1 X 2,3
Connection dimension inlet:
76,1 X 2,3
CV-Value:
337,0 gal/min
Kvs-value:
283.0 MQH
Nominal pressure:
PN 50
nominal size:
DN 65
cleaned for oxygen service:
ISO 23208
Maximum allowable temperature:
120.0 °C
Maximum allowable temperature:
-196.0 °C
installation height:
440.0 MMT
Article-No.: 09340P6576.0021
Price
Open product details
128 Products
of 11
Sort By

Gate Valve

The Cryo gate valve has a flow rate three to five times higher than comparably sized globe valves. This saves valuable time when filling trailers and delivering cryogenic liquefied gases to customers. Cryogenic gate valves are available in sizes DN25 to DN100 and secure pressures up to 50 bar, at operating temperatures from -196°C up to +120°C.
