Article-No.: 06405.0250.0000
Price
POR
POR

Changeover Valve DN25(1")
Article-No.: 06405.0250.0000
- Solution:
- LNG, Air Gases
- Solution Area:
- Transport, Storage, Refueling
- Maximum allowable temperature:
- -196.0 °C
- Maximum allowable temperature:
- 185.0 °C
- cleaned for oxygen service:
- ISO 23208
- nominal size:
- DN 25
- Nominal pressure:
- PN 45
- Kvs-value:
- 14.0 MQH
- CV-Value:
- 16,1 gal/min
- Connection dimension inlet:
- 1"
- Connection dimension outlet:
- 1''
- Connection inlet:
- female thread BSPP
- Connection outlet:
- female thread BSPP
Price
POR
POR

Article-No.: 06405.0150.6000
Price
POR
POR

Changeover Valve DN15(1/2")
Article-No.: 06405.0150.6000
- Solution:
- LNG, Air Gases
- Solution Area:
- Transport, Storage, Refueling
- Maximum allowable temperature:
- -196.0 °C
- Maximum allowable temperature:
- 185.0 °C
- cleaned for oxygen service:
- ISO 23208
- nominal size:
- DN 15
- Nominal pressure:
- PN 40
- Kvs-value:
- 6.0 MQH
- CV-Value:
- 6,9 gal/min
- Connection dimension inlet:
- 3/4''
- Connection dimension outlet:
- 1/2''
- Connection inlet:
- female thread NPT
- Connection outlet:
- female thread NPT
Price
POR
POR

Article-No.: 06405.2047.C020
Price
POR
POR

Changeover Valve DN15(1/2")
Article-No.: 06405.2047.C020
- Solution:
- LNG, Air Gases
- Solution Area:
- Transport, Storage, Refueling
- Maximum allowable temperature:
- -196.0 °C
- Maximum allowable temperature:
- 185.0 °C
- cleaned for oxygen service:
- ISO 23208
- nominal size:
- DN 15
- Nominal pressure:
- PN 40
- Kvs-value:
- 6.0 MQH
- CV-Value:
- 6,9 gal/min
- Connection dimension inlet:
- 33,7 x 3,2 / 1'' S40
- Connection dimension outlet:
- 1/2''
- Connection inlet:
- SCHWEIßKUGELBUCHSE
- Connection outlet:
- female thread BSPP
Price
POR
POR

Article-No.: 06401.0150.0000
Price
POR
POR

Changeover Valve DN15(1/2")
Article-No.: 06401.0150.0000
- Solution:
- LNG, Air Gases
- Solution Area:
- Transport, Storage, Refueling
- Maximum allowable temperature:
- -196.0 °C
- Maximum allowable temperature:
- 185.0 °C
- cleaned for oxygen service:
- ISO 23208
- nominal size:
- DN 15
- Nominal pressure:
- PN 125
- Kvs-value:
- 4.0 MQH
- CV-Value:
- 4,6 gal/min
- Connection dimension inlet:
- G3/4
- Connection dimension outlet:
- G3/4
- Connection inlet:
- SPANNMUFFE
- Connection outlet:
- SPANNMUFFE
Price
POR
POR

Article-No.: 06405.2510.6360
Price
POR
POR

Changeover Valve DN25(1")
Article-No.: 06405.2510.6360
- Solution:
- LNG, Air Gases
- Solution Area:
- Transport, Storage, Refueling
- Maximum allowable temperature:
- -196.0 °C
- Maximum allowable temperature:
- 185.0 °C
- cleaned for oxygen service:
- ISO 23208
- nominal size:
- DN 25
- Nominal pressure:
- PN 40
- Kvs-value:
- 14.0 MQH
- CV-Value:
- 16,1 gal/min
- Connection dimension inlet:
- 1"
- Connection dimension outlet:
- 1''
- Connection inlet:
- female thread NPT
- Connection outlet:
- female thread NPT
Price
POR
POR

Article-No.: 06405.0250.C000
Price
POR
POR

Changeover Valve DN25(1")
Article-No.: 06405.0250.C000
- Solution:
- LNG, Air Gases
- Solution Area:
- Transport, Storage, Refueling
- Maximum allowable temperature:
- -196.0 °C
- Maximum allowable temperature:
- 185.0 °C
- cleaned for oxygen service:
- ISO 23208
- nominal size:
- DN 25
- Nominal pressure:
- PN 45
- Kvs-value:
- 14.0 MQH
- CV-Value:
- 16,1 gal/min
- Connection dimension inlet:
- 1"
- Connection dimension outlet:
- 1''
- Connection inlet:
- female thread BSPP
- Connection outlet:
- female thread BSPP
Price
POR
POR

Article-No.: 06405.0150.6009
Price
POR
POR

Changeover Valve DN15(1/2")
Article-No.: 06405.0150.6009
- Solution:
- LNG, Air Gases
- Solution Area:
- Transport, Storage, Refueling
- Maximum allowable temperature:
- -196.0 °C
- Maximum allowable temperature:
- 185.0 °C
- cleaned for oxygen service:
- ISO 23208
- nominal size:
- DN 15
- Nominal pressure:
- PN 40
- Kvs-value:
- 6.0 MQH
- CV-Value:
- 6,9 gal/min
- Connection dimension inlet:
- 33,7 / 1''
- Connection dimension outlet:
- 1/2''
- Connection inlet:
- LOETMUFFE
- Connection outlet:
- female thread NPT
Price
POR
POR

Article-No.: 06401.0150.9021
Price
POR
POR

Changeover Valve DN15(1/2")
Article-No.: 06401.0150.9021
- Solution:
- LNG, Air Gases
- Solution Area:
- Transport, Storage, Refueling
- Maximum allowable temperature:
- -196.0 °C
- Maximum allowable temperature:
- 185.0 °C
- cleaned for oxygen service:
- ISO 23208
- nominal size:
- DN 15
- Nominal pressure:
- PN 125
- Kvs-value:
- 4.0 MQH
- CV-Value:
- 4,6 gal/min
- Connection dimension inlet:
- G3/4
- Connection dimension outlet:
- G3/4
- Connection inlet:
- SPANNMUFFE
- Connection outlet:
- SPANNMUFFE
Price
POR
POR

Article-No.: 06401.0150.9015
Price
POR
POR

Changeover Valve DN15(1/2")
Article-No.: 06401.0150.9015
- Solution:
- H2, LNG, Air Gases
- Solution Area:
- Manufacturing, Transport, Storage, Application, Refueling
- Maximum allowable temperature:
- -196.0 °C
- Maximum allowable temperature:
- 185.0 °C
- cleaned for oxygen service:
- ISO 23208
- nominal size:
- DN 15
- Nominal pressure:
- PN 100
- Kvs-value:
- 4.0 MQH
- CV-Value:
- 4,6 gal/min
- Connection dimension inlet:
- DN40 PN100
- Connection dimension outlet:
- G3/4
- Connection inlet:
- flange DIN EN ISO 1092-1
- Connection outlet:
- SPANNMUFFE
Price
POR
POR

Article-No.: 06405.0150.0000
Price
POR
POR

Changeover Valve DN15(1/2")
Article-No.: 06405.0150.0000
- Solution:
- LNG, Air Gases
- Solution Area:
- Transport, Storage, Refueling
- Maximum allowable temperature:
- -196.0 °C
- Maximum allowable temperature:
- 185.0 °C
- cleaned for oxygen service:
- ISO 23208
- nominal size:
- DN 15
- Nominal pressure:
- PN 40
- Kvs-value:
- 6.0 MQH
- CV-Value:
- 6,9 gal/min
- Connection dimension inlet:
- 3/4''
- Connection dimension outlet:
- 1/2''
- Connection inlet:
- female thread BSPP
- Connection outlet:
- female thread BSPP
Price
POR
POR

Article-No.: 06401.0150.9048
Price
POR
POR

Changeover Valve DN15(1/2")
Article-No.: 06401.0150.9048
- Solution:
- H2, LNG, Air Gases
- Solution Area:
- Manufacturing, Transport, Storage, Application, Refueling
- Maximum allowable temperature:
- -196.0 °C
- Maximum allowable temperature:
- 185.0 °C
- cleaned for oxygen service:
- ISO 23208
- nominal size:
- DN 15
- Nominal pressure:
- PN 160
- Kvs-value:
- 4.0 MQH
- CV-Value:
- 4,6 gal/min
- Connection dimension inlet:
- DN15 PN160
- Connection dimension outlet:
- G3/4
- Connection inlet:
- flange DIN EN ISO 1092-1
- Connection outlet:
- SPANNMUFFE
Price
POR
POR

Article-No.: 06401.0250.9045
Price
POR
POR

Changeover Valve DN25(1")
Article-No.: 06401.0250.9045
- Solution:
- LNG, Air Gases
- Solution Area:
- Transport, Storage, Refueling
- Maximum allowable temperature:
- -196.0 °C
- Maximum allowable temperature:
- 185.0 °C
- cleaned for oxygen service:
- ISO 23208
- nominal size:
- DN 25
- Nominal pressure:
- PN 125
- Kvs-value:
- 13.0 MQH
- CV-Value:
- 15,0 gal/min
- Connection dimension inlet:
- G1
- Connection dimension outlet:
- G1
- Connection inlet:
- SPANNMUFFE
- Connection outlet:
- SPANNMUFFE
Price
POR
POR
