TT-Schieber-STV DN50 RA60,3 PN50
Click on the product image for a larger view.
TT-Schieber-STV DN50 RA60,3 PN50
Article-No.: 09343.5060.T024
Price
POR
Description
Cryogenic gate valve DN50 PN50
cleaned and degreased for oxygen service
with bonnet extension H=550(600)
with pneumatic actuator
working temperature -196°C up to +120°C
body 1.4308 st.st.
bonnet 1.4301 st.st.
gland packing graphit/PTFE
slide bush CW452K bronze
connection socket end OD60.3mm
face to face 110mm
mounted with rubber bellow actuator
test pressure: 5 - 50 bar, leakage class A according to DIN EN 12266
test pressure: 0,7 - 4,9 bar, leakage class B according to DIN EN 12266
air connection for actuator Push-In connection for tube
diameter 8.0mm
cleaned and degreased for oxygen service
with bonnet extension H=550(600)
with pneumatic actuator
working temperature -196°C up to +120°C
body 1.4308 st.st.
bonnet 1.4301 st.st.
gland packing graphit/PTFE
slide bush CW452K bronze
connection socket end OD60.3mm
face to face 110mm
mounted with rubber bellow actuator
test pressure: 5 - 50 bar, leakage class A according to DIN EN 12266
test pressure: 0,7 - 4,9 bar, leakage class B according to DIN EN 12266
air connection for actuator Push-In connection for tube
diameter 8.0mm
Delivery Time:
7 week(s)
More Information
| SKU | 09343.5060.T024 |
|---|---|
| Delivery Time | 7 |
| Solution | LNG, Air Gases |
| Solution Area | Transport, Storage, Refueling, Processes |
| Type (Series) | 09343 |
| Maximum allowable temperature | -196.0 °C |
| Maximum allowable temperature | 120.0 °C |
| cleaned for oxygen service | ISO 23208 |
| nominal size | DN 50 |
| Nominal pressure | PN 50 |
| max. lift | 50.0 |
| Kvs-value | 125.0 MQH |
| body material | 1.4308 |
| CV-Value | 149,0 gal/min |
| Connection dimension inlet | 60,3 / 2'' |
| Connection dimension outlet | 60,3 / 2'' |
| Connection inlet | socket weld connection |
| Connection outlet | socket weld |
| Canada approval | CRN OC15238.5C |
